Holcim Cement Complete Slag Grinding Plant

4996 Freedom Way
Weirton, WV 26062

Property Description

Complete Slag Grinding plant currently located in Weirton, West Virginia. This equipment is capable of producing 38 tons per hour of Type 120 Blast Furnace Slag Cement. The circuit is complete with all major processing equipment supplied by Polysius in 1990, as well as, the material handling equipment as required. Additionally, an extensive set of spares is included in the package. Once refurbished, this circuit would be capable of processing: Slag Cement, Pozzolan, OPC Cement, Copper or Silver liberation, Diamond liberation or any other ore and other materials that are friable.

Contact Information

Tim Watters

Equipment List

Download Equipment List

Offered in Partnership With

Hilco Industrial, LLC, Redstone Moore Co.

Equipment Summary

  • Polysius POLYCOM® High Pressure Grinding Roll: Size: 14 / 8, Roll Diameter: 1.4M, Roll Width: 750 mm, Capacity: 236 stph (recirc load of 6+), Motor Size: 2 x 600 hp
  • Polysius SEPOL® High Efficiency Separator: Separator Type: SV 200/0, Airflow:63,200 acfm, Motor Size: 200 hp
  • Polysius Shaft Dryer / Air Heater / Cyclone / Fan: Capacity: 25 mbtu/h, Fuel: Natural Gas, Cyclone Diameter: 10 ft, Air Volume: 40,000 acfm, Temperature:250°F, Motor Size: 250 hp

Industries This Plant Serves

  • Slag Grinding
  • Glass Grinding
  • Copper Liberation
  • Silver Liberation
  • Gold Liberation
  • Diamond Liberation
  • Pozzolan Grinding
  • Iron Ore Grinding
